1. Scope

1.1 Operation and Maintenance Plan Identification

The Operation and Maintenance (O&M) Plan provides <defunct>.com with the policies and procedures for the managing company equipment and systems. The control, maintenance and execution of activities documented herein are under the responsibility of <defunct>’s Operations Group (OG). Identification of responsibilities and sequences of major activities related to the managing company assets are established by this document.

1.2 Objectives

Through policy declaration, this document specifies the commitment to managing O&M processes for all <defunct> projects. OG personnel shall execute the procedures defined in this document to maintain consistent and approved actions.

1.3 Internet Website Overview

The <defunct>.com system is designed to be an Internet Trading HUB. This Trading HUB will provide a forum for buyers and sellers of metal working machine tools to trade used equipment, order third party ancillary support, and learn about the Industry in general.

The components that make up the <defunct>.com system will be designed for:

Ø High information throughput, rapid network response,

Ø Secure transactions,

Ø Ease of use and functionality using a browser based interface

Ø Integration with third party software and communication interfaces,

Ø A high degree of flexibility in administration of configuration of the system.

The website application is predominantly comprised using Commercial off the Shelf Software (COTS) developed by and Independent Software Vendor (ISV). Object oriented middleware (both custom and commercial) and fast network response times will be instituted. Scalability, in the form of component TCP/IP (WWW) services installed into a UNIX server environment, will be practiced.

The website is the primary mode of commerce and revenue. It is co-located at a remote site with connections to our business office. The co-location site hosts our hardware, network, firewalls, and application software. The following areas shall fall under O&M management.

1.3.1 Application Software

The auction application, website monitor, Enterprise Resource Planning (ERP) software and Customer Relationship Management (CRM) software shall be managed.

1.3.2 Host Machines

Hardware servers are comprised of Sun, Dell and Compaq servers. These are networked to the Internet to form our website. We shall manage backup and recovery systems within this procedure.

1.3.3 Network

The Ethernet LAN, routers, switches and hubs comprising the physical connection between host machines, firewalls and private networks shall be managed. We shall assess our security measures against attack, monitor authorization and authentication, and manage failure recovery.

1.3.4 Internet Gateway

This is comprised of our Internet Service Provider’s (ISP) domain service, access to tier-one Internet and both availability and performance of our services to the North American Internet users.

1.3.5 Communication Channels

Our communications channels consist of help and FAQ pages, customer self-service pages, email, chat and telephone communications between our website, our outsourced customer service site (operated by service.com) and our business site. We shall monitor, control and manage each channel.

1.4 Document Overview

This document will define management policies and procedures relevant to operating all company assets. This information will be broken into the following areas.

Ø System Design – hardware and software components

Ø Policies – responsibilities, commitment to perform and organizational philosophy

Ø Fault management – surveillance and control, trouble report handling, work order handling and escalation procedures

Ø Configuration management – change requests and configuration control

Ø Performance management – performance measurement, monitor service quality trends, supply of statistical information as a basis for expansion

Ø Spare parts maintenance – availability of spare parts

Ø Field maintenance – corrective and preventative maintenance

Ø Diagrams – network details, tables and report templates

2. Definitions

The following definitions apply to this document:

TBD

The following acronyms apply to this document:

Acronym	Meaning
CPU	Central Processing Unit
CRM	Customer Relationship Management
CSC	Computer Software Component
CSU	Computer Software Unit
ERP	Enterprise Resource Planning
HW	Hardware
I/F	Interface
ISP	Internet Service Provider
OG	Operations Group
O&M	Operation and Management
OMP	Operation and Management Plan
RMA	Reliability/Maintainability/Availability
SW	Software

3. System Design

3.1 Overview

Figure 1 – Business Sites

Our business computing machinery are grouped into three networks: a co-location center housing the production equipment, which is located at a network operations center (NOC) hosted by SimpleNet, network equipment supporting business activities at our business site and communication equipment supporting outsourced customer service activities provided by service.com. <defunct>.com is company domain name.

3.1.1 Network Description

Figure 2 – Network and Phone Topology

Web servers and application servers are networked to the Internet through a firewall. A private connection exists between the NOC and the business site, which allows website administration, access to the business accounting software and web site record keeping. Another private connection exists between the NOC and service.com, which guarantees private communication supporting customer service activities. The business site uses a separate firewall for its Internet access.

All computing equipment is supported by battery-backup power supply to cover the contingency of power loss. The network is designed to provide 100 Mbit/sec data transfer rates. Appropriate routers and switches are strategically placed to provide high security and network bandwidth.

3.1.2 Capacity and Volume

The operational website and associated application software provides sufficient data storage and processing capabilities to support the following “go-live” web traffic requirements. Scale and performance during specification of hardware shall use a multiplier of 10 against each metric.

Ø Auction transactions (where the purchase is consummated): 40 per day

Ø Catalog transactions (where the purchase is consummated): 400 per day

Ø Unique visits: 2,000 per day

Ø Web hits: 10,000 per day

Ø When anticipating number of bids per auction transaction, use a multiplier of 10 (i.e. 400 bids per day). Use the 10-multiplier for catalog item selection/deselecting as well (i.e. 4000 shopping cart additions or removals per day).

Ø Anticipate a skewed activity log where Monday is the highest activity day, followed by Tuesday, then Thursday, Wednesday and Friday. Anticipate almost no activity over Saturday or Sunday.

Ø We estimate weekly traffic load as follows: 35% Monday, 25% Tuesday, 15% Thursday, 10% Wednesday, 7% Friday, 7% Saturday & Sunday.

Ø The telephone support system provides sufficient capacity and processing capabilities to support the following caller traffic requirements.

Ø Web 1-800 help handled by service.com: 100 per day

Ø General 1-800 information handled by service.com: 200 per day

Ø Specialized 1-800 help by our staff: 100 per day

Ø General 1-858 business communication by our staff: 1000 per day

3.2 Business Offices: Locations, Telephone Numbers, Primary Contacts

Primary business activities are carried out at <defunct>.com business office with address:

Ø <defunct>.com business site

Ø <snip>

Ø <defunct>.com production (Internet) hardware and programmed software housed at co-location center

Ø <defunct>.com website at SimpleNet

Ø <snip>

3.3 Co-location Site

The co-location site is used to house the hardware for our firewalls, web monitors, web servers, application servers, database servers and supporting networking hardware. A NOC is used to house the co-location center’s critical production computing devices since it provides around-the-clock security, earthquake proofing, and special fire retardant systems.

All computing equipment co-located at the NOC is powered on a battery-backup power supply to cover the contingency of power loss at the NOC. The network connecting these computing systems provides 100 Mbit/sec data transfer rates. Appropriate routers and switches are strategically placed to provide high security and network bandwidth. Static IP’s are used at the co-locate site to enable the firewall to control the highest degree of security and minimize the processing requirements of the servers.

Web servers and application servers are networked to the Internet through a firewall. A private connection between NOC and business site provides sufficient bandwidth between application servers to prevent degradation. Static IP’s are assigned to computers to enable the firewall to control the highest degree of security.

See Appendix C for Co-Location Site Network Diagram.

3.3.1 Hardware

3.3.1.1 Switch

The required switch configuration is the following:

· Cisco 2912XL

3.3.1.2 Routers

The required router configuration is the following:

· Cisco 2610

· CSU/DSU

3.3.1.3 Firewall

The required firewall configuration is the following:

· Sun Ultra 10 Web Server

· 333 MHz processor

· 1GB memory

· 10 GB of disk space (highly dependent on user requirements)

· SVGA Video card

· Monitor (80 MHz, 1024 x 768 screen resolution)

· Mouse

· Keyboard

· UPS (Uninterrupted Power Supply)

· Ethernet network adapter (10/100 NIC card)

3.3.1.4 Web Page Monitor

The Web Monitor supports the following functionality for our product to operate efficiently:

· Support 10,000 web hits per day without impact to other network/Internet resources.

· There shall be enough free disk space to contain the UNIX operating system, database and the web monitor software.

· A monitor shall attach to the server to enable system control and administration.

· The required web server configuration is the following:

· Sun Ultra 10 Web Server

· 333 MHz processor

· 1GB memory

· 10 GB of disk space (highly dependent on user requirements)

· SVGA Video card

· Monitor (80 MHz, 1024 x 768 screen resolution)

· Mouse

· Keyboard

· UPS (Uninterrupted Power Supply)

· Ethernet network adapter (10/100 NIC card)

3.3.1.5 Web Page Server (phase 2)

The Web Server shall support the following functionality for our product to operate efficiently:

· Support 10,000 web hits per day without performance degradation to the background network processes.

· There shall be enough free disk space to contain the UNIX operating system and the web server software.

· A monitor shall attach to the server to enable system control and administration.

· The required web server configuration is the following:

· Sun Ultra 10 Web Server

· 333 MHz processor

· 1GB memory

· 10 GB of disk space (highly dependent on user requirements)

· SVGA Video card

· Monitor (80 MHz, 1024 x 768 screen resolution)

· Mouse

· Keyboard

· UPS (Uninterrupted Power Supply)

· Ethernet network adapter (10/100 NIC card)

3.3.1.6 Disk Array

The required mirrored disk array configuration is the following:

3.3.1.7 Tape Backup

The required tape configuration is the following:

· Sun DLT 1000

3.3.1.8 Application Servers

Application, middleware and database server software will execute on this high performance hardware. The server will communicate to the web server(s) over a network. The Auction Server shall support the following functionality for our product to operate efficiently:

· There shall be enough free disk space to contain the application server software.

· Support JSP, Java servlets and JDBC without performance degradation to the background network processes.

· Support for SSL, HTTP through firewall

· There shall be enough free disk space to contain the UNIX operating system, the application database software, and Oracle Server (8.1.5).

· The GUI portion of administrative tools distributed with the software requires a screen resolution of 1024 x 768 pixels (large fonts) with a minimum color depth of 256 colors. An appropriate SVGA monitor shall be installed.

The required production server configuration is the following:

· Sun Enterprise 450 application and database server

· 400 MHz processor

· 256 MB memory

· 100 GB of disk space (highly dependent on user requirements)

· SVGA Video card

· Monitor (80 MHz, 1024 x 768 screen resolution)

· Mouse

· Keyboard

· UPS (Uninterrupted Power Supply)

· Ethernet network adapter (10/100 NIC card)

3.3.1.9 ERP Server

Financial accounting software will execute on this high performance hardware. The server will communicate between applications and the business site. The ERP Financial Accounting Server shall support the following functionality for our product to operate efficiently:

· There shall be enough free disk space to contain the financial application software.

· Support ODBC and JDBC without performance degradation to the background network processes.

· There shall be enough free disk space to contain the UNIX operating system, the financial accounting software, Oracle Server (8.0.5), and the financial accounting database.

The required Financials Database server configuration is the following:

· Sun Enterprise 250 application and database server

· 300 MHz processor

· 1GB memory

· 100 GB of disk space (highly dependent on user requirements)

· SVGA Video card

· Monitor (80 MHz, 1024 x 768 screen resolution)

· Mouse

· Keyboard

· UPS (Uninterrupted Power Supply)

· Ethernet network adapter (10/100 NIC card)

3.3.1.10 CRM Application Server

Customer Relationship Management software will execute on this high performance hardware. The server will communicate between service.com outsource company and the co-location site. The CRM Server shall support the following functionality for our product to operate efficiently:

· There shall be enough free disk space to contain the CRM application software.

· Support ODBC without performance degradation to the background network processes.

· There shall be enough free disk space to contain the Windows NT server operating system, the CRM software, MS SQLServer7.0), and the CRM database.

The required CRM server configuration is the following:

· Dell xj500 server

· Dual 300 MHz processor

· 1GB memory

· 100 GB of disk space (highly dependent on user requirements)

· SVGA Video card

· Monitor (80 MHz, 1024 x 768 screen resolution)

· Mouse

· Keyboard

· UPS (Uninterrupted Power Supply)

· Ethernet network adapter (10/100 NIC card)

3.3.1.11 CRM E-Mail Server

Customer Relationship Management email software will execute on this high performance hardware. The server will communicate between service.com outsource company and the co-location site. The CRM Server shall support the following functionality for our product to operate efficiently:

· There shall be enough free disk space to contain the CRM email application software.

· Support ODBC without performance degradation to the background network processes.

· There shall be enough free disk space to contain the Windows NT server operating system, the CRM email software, MS SQL (5.0), and the email database.

The required CRM email server configuration is the following:

· Dell xj500 server

· 300 MHz processor

· 256 MB memory

· 20 GB of disk space (highly dependent on user requirements)

· SVGA Video card

· Monitor (80 MHz, 1024 x 768 screen resolution)

· Mouse

· Keyboard

· UPS (Uninterrupted Power Supply)

· Ethernet network adapter (10/100 NIC card)

3.3.2 Software

3.3.2.1 Database

3.3.2.1.1 Overview

There are five Oracle database instances and one Microsoft SQL Server at the co-location site. Three of the Oracle instances support the Oracle Financial Applications, run on the E-250, and use Oracle8 software. One instance is used by Moai Live Exchange, which runs on the E-450, and uses Oracle8i software, and the fifth instance is used by the Accrue Insight collection & reporting tool, currently runs on the E-450, and uses Oracle8i software. The single Microsoft SQL Server instance is used by the Octane Customer Relationship Management (CRM) software, runs on a dedicated NT dual processor machine, and uses the version 7 Microsoft products.

3.3.2.1.2 Installation

3.3.2.1.3 Patches/Releases

We are currently running 8.1.5.1 on Leai and Tatooine. Skywalker has not had the current patch installed. There is already a .2 patch available for special circumstances, and a .3 promised, as well as a new release, 8.1.6 (also referred to as 8i Second Release).

The 8.1.5.1 patch fixed several Recovery Manager and interMedia context indexes (sic) problems.

3.3.2.1.4 RAID

See Appendix B for description of RAID.

3.3.2.2 Firewall

Multiple servers handle web page creation via the connection to the Internet through a firewall. The firewall application is the only application running on the firewall servers. We have chosen Checkpoint’s Firewall-1 as the application of choice. It is configured to allow only HTTP and HTTPS protocols passage to our web server(s). The firewall is also configured to announce the IP of our web server to the Internet.

· Operating System: Sun Solaris version 2.6

· <snip>

3.3.2.3 Web Page Monitor

Our network analysis software, Accrue Insight, uses the Oracle8i database software. Two extra cost Oracle8i options are required for this installation: the partitioning option, and the parallel query option. Accrue states the latter as being the "bitmapped index" option; however, there is no such option. Bitmapped indices are part of the parallel query option.

The files from the Accrue "collector" are stored in naboo::/insight/var/log. There are two files here every hour of every day. The files for the current hour and the previous hour are not compressed. Files prior to these are compressed in the .gz format. While these files could be uncompressed and edited, it's more likely that the database would be cleared and the "transformer" would be used to filter unwanted records. Insight operates in a batch mode. Files are loaded into the database at 9:30 PM and 1:30 AM. The 9:30 load is referred to as the "mini load", and the 1:30 load as the "nightly load". The nightly load also does reports. These loads are done from two entries in the "goldmine" user account crontab file.

<xxx insert crontab –l output here>

After the nightly load, the files are moved from naboo::/insight/var/log to naboo::/insight/var/archive. The /insight/var mount point will be moved onto another file system.

<xxx insert name of file system here>

Accrue documentation recommends that you run Oracle in "noarchivelogmode". This recommendation was not in the "quick start" sheet that was read prior to the installation, so we were initially running in archive log mode; however, the reasons for not running in archive log mode where only protective, and Accrue agrees that the recommendation was based on "keeping it simple". We monitor our systems six times a day to monitor the disk utilization.

Without archive log mode we cannot do "hot backups", implement Oracle Recovery Manager (R*Man), or do point in time recovery. There is a performance hit for running in this mode however. The instance will run faster in noarchivelogmode, and will consume less disk space. It will have to be down periodically for cold backups (i.e., scheduled maintenance), or be captured in a logical backup (schema export). Both a little more trouble than hot backups, or using the R*man/Veritas libraries to operate the tape drive directly. In the event we have a database failure, we may want to just rebuild the schema and reload the data from the collector files -- depending on size and duration of those stored collector files.

The steps required to rebuild are documented in Appendix D: Steps to Rebuild the Accrue Oracle Database Schema.

Because all data resides in the log and archive directories, the archive log mode in the Accrue Oracle instance has been turned off.

3.3.2.4 Web Page Server (phase 2)

· Operating System: Sun Solaris version 2.6

· <snip>

3.3.2.5 Application Server 1

Our auction software, Moai Live Exchange, uses the Oracle8i database software. While the interMedia component (context indexes) is not an extra cost option, it is a product, which was developed by another team of developers, and as a result, it is not as “robust” as some of the other Oracle components. There are tricks to the installation and operation, which are described in the following sections (4.3.2.5.1 through 4.3.2.5.4).

The Application Server 1 configuration follows:

· Operating System: Sun Solaris version 2.6

· <snip>

3.3.2.5.1 Installation

When doing a fresh install, including Oracle8i libraries, into a new “ORACLE_HOME” structure, if you specify the location for the Oracle “datafiles” for all components, as we do, there will be no location for the data file associated with the “context option” (8i “interMedia”), and the installation will fail. The dbassist tool is not smart enough to prompt to relocate the context data file, and not smart enough to create a directory if it doesn’t exist.

3.3.2.5.2 Start & Stop Operations

With the exception of the Accrue instance, all production Oracle databases are run in the archive log mode. This is the safest way to assure point-in-time recovery. What happens here is that every transaction is processed in an Oracle “redo log”, when the active online redo log is filled it is switched, a new log becomes current, and the previously filled log is archived. With these archived logs, it is possible to restore “hot backups” to a point-in-time before a failure occurred. Hot backups are taken while the system is available to the user, as compared to cold backups of operating system files, or logical backups (exports) taken in Oracle’s “exclusive” (single user) mode. Archived redo logs cannot be applied to restores of cold backups, or imports of export dump files.

The Accrue instance does not run in archive log mode for reasons discussed in section 4.3.2.3 Web Page Monitor.

The sequence recommended by Oracle to shutdown the system is as follows:

% su root

# shutdown -y -g0 -i6

If the Unix “boot”, “reboot”, or “init 6” commands are used the database does not shutdown with the automatic shutdown script “dbshut”. These commands are not reading the shutdown script in the “/etc/rc0.d” directory.

Issuing the “shutdown” command executes the scripts in the above directory.

For the Moai and Accrue Oracle instance’s automatic startup and shutdown configurations please see Appendix E: Production Oracle Auto Start and Shutdown.

There is one Unix “crontab” file on the production server (Tatooine).

The Oracle user’s crontab file contains the following entries:

# Compress the archive redo logs every 15 minutes

0,15,30,45 * * * * /u02/app/oraprd/dba/comparch PRD > /dev/null 2>&1

# Perform database checks for OraLogs - D.Russell 01/2000

45 03,07,11 * * 0-6 /u01/app/oracle/scripts/database_checks.sh >/dev/null 2>&1

45 15,19,23 * * 0-6 /u01/app/oracle/scripts/database_checks.sh >/dev/null 2>&1

# Analyze Moai Tables Daily - D.Russell 01/2000

00 04 * * 0-6 /u01/app/oracle/scripts/analyze_tables.sh >/dev/null 2>&1

# Perform Hot Backup to Disk Daily - D.Russell 01/2000

00 02 * * 0-6 /u01/app/oracle/scripts/hot_disk.sh >/dev/null 2>&1

The entries in this facility cause several database actions to occur at preferred intervals. Obviously, activities such as tape backups of file systems should occur after the completion of the Oracle hot backups.

There is one Unix “crontab” file on the production Web Page Monitor (Naboo). This file is located in the “Goldmine” user’s account and contains the following information:

4 * * * * /insight/bin/gziplogs.pl /insight/var/logs >/dev/null 2>&1

30 1 * * * /insight/bin/nightly.pl > /insight/var/status/nightly.log 2>&1

30 21 * * * /insight/bin/find_load > /insight/var/status/find_load_cron_log 2>&1

10 * * * * /insight/bin/notify >/insight/var/status/notify_log 2>&1

The goldmine crontab may be discussed elsewhere; however, one of these entries, nightly.pl, also performs the periodic Oracle table analysis which is required for the Cost Based Optimizer (CBO) of Oracle.

3.3.2.5.3 Execution

The method to start the context server is not automated. The files, which start the listener and database, do not start the context server. This is currently a manual process, which is accomplished, as follows:

$ORACLE_BASE/scripts/start_context.sh

This process will be automated in the future. The context server is not necessary in order to use context indexes (sic). It is only necessary for background processes, which re-index the fields.

While it doesn’t seem to hurt to shutdown Oracle and/or reboot the Unix operating system without shutting down the context server, it could corrupt indexes (sic) if the background process was executing which required the context server. With that in mind, we have created the follow script to shutdown the context server:

$ORACLE_BASE/scripts/stop_context.sh

If you neglect to stop the context server and restart the machine or the database, the context server process will stop because it is also a process within Oracle, and it will need to be manually restarted using the procedure above.

3.3.2.5.4 Maintenance

Context indexes (sic) rely on the Oracle cost based optimizer (CBO). Queries written for the rules based optimizer (RBO) have a different structure. Once a table has been “analyzed”, it is automatically queried using the CBO technique. There is a daily crontab entry in the Unix Oracle account to analyze the Moai tables, as follows:

# Analyze Moai Tables Daily - D.Russell 12/1999

00 04 * * 0-6 /u01/app/oracle/scripts/analyze_tables.sh >/dev/null 2>&1

It is not a good idea to analyze all tables routinely, and absolutely not a good idea to analyze the “sys” and “system” data dictionary tables. In the event that tables that should not be analyzed accidentally are analyzed, we have techniques, which will reverse the analysis and remove the statistics.

3.3.2.5.5 Verification

The easiest way to tell if the context server is running is to execute the following UNIX command:

ps –elf |grep –i ctx

A more complicated alternative from SQL*Plus follows:

select osuser, type, program from v$session

where program like ‘ctxsrv%’;

This shows you that the context server is not just a Unix process but is defined within Oracle as being an Oracle process.

3.3.2.6 ERP Server

Oracle Enterprise Resource Planning (ERP) a.k.a., Oracle Financials

<defunct>.com implemented the following modules of Oracle Financials: General Ledger, Accounts Receivable, Accounts Payable, Fixed Assets, Purchasing, Inventory, and Order Entry. Three instances are maintained: Production (PRD), Test (TST), and Vision (VIS).

The Production instance contains the production financial records for the company. The Test instance is for testing both code and operational changes and enhancements. The Finance department uses the Test instance to verify, for example, that new procedures correctly update journals, before implementing the new procedures in Production. It is imperative that both the PRD and TST instances be available at all times to the Finance department. The TST and PRD setups must be the same at all times.

The Vision database is fully configured to showplace virtually all of Oracle’s functionality. It is available for investigating the impact of new transactions that are outside the current scope of the system. As <defunct>.com grows and enters new markets, the Vision database will be used to see how complex transactions are configured and to understand process flows in an environment that may be different from our current system. Vision only needs to be running at that time when such investigations take place. At all other times, Vision should be shut down to preserve system resources.

Each instance has its own binaries, so that both application and database patches can be applied first in the TST environment, and then, after successful testing of the changes, applied to PRD. All changes, no matter small, must be applied first to TST.

The Oracle Financials Implementation Technical Reference is a comprehensive guide that was written to cover the setup and configuration of the Oracle Financials at <defunct>.com. The sections include Oracle Support, TARs, Patches, Scripts, Physical DB Design, Veritas and Oracle, RAID and Oracle, Technical Bulletins, Applications Sizing, an Engagement Summary of installation and setups of all three instances, custom printer configurations, Tuning of Oracle I/O, Documentation, Host Environments, Error Screen Shots, Read Me Section, Moai Integration with Oracle Financials, Tradesafe Specs, Correspondence, and Notes. This book is always located in the bookshelf of the Database Architect.

A comprehensive two-volume set covers the functional setup. Volume I covers Acceptance Certificates of ERP project manager Progress Reports, the Chart of Accounts configuration, the Flexfields setup for <defunct>.com, Oracle contracts, FastForward Standard Fuctionality, Training, Oracle consultants backgrounds, Schedules and Tasks, and Oracle Reports.

Volume II covers FastForward Financials, FastForward Inventory and Order Entry, the Scope, Objectives and Approach of the Financials Implementation, Site Assessment, and Process Flows.

An additional multi-volume set of detailed setup screens for each module, including all month end closing procedures was also prepared. These documents are located in the Finance department, in the Accounting Manager’s bookcase.

Each module has two types of documentation: functional and technical, and is shared between the Finance Department and Database Architect.

The ERP configuration follows:

· Operating System: Sun Solaris version 2.6

· <snip>

3.3.2.7 CRM Application Server

As our out-source help facility, service.com answers first tier email, phones and live chat requests from our homepage. In the process, they use the Octane software which is a database based application owned by <defunct>.com. Octane's features include contact management, customer care, help desk, and product (defect) tracking.

Contact management is used by service.com to collect customer contact information when a customer chooses to not register as buyer or seller. <defunct>.com has created an interface between the customer records in Octane and the customer data contained in Moai. This modification was done in Octane's default database schema to add one column in b_entity called c_userOID, which service.net will use to identify if the customer is already registered in Live Exchange's database or Octane's database. A Javascript servlet on the Oracle/Moai side was written to do the data sync.

In its’ next release, we will receive sales force automation and market campaign analysis. The interfaces to other components will change with that release, as well.

Additional modifications have been made to the Octane database “b_octane” schema by service.com. The script, which makes this modification, has been loaded into Visual Source Safe (VSS), which was also installed on the Octane server.

Because the changes were database "alters" they do not appear numerically, alphabetically, or logically, in sequence. The changes are presented, as required.

The CRM configuration follows:

· Operating System: Windows NT server version 4.0, SP 5

· <snip>

3.3.2.8 CRM E-Mail Server

The CRM E-Mail Server configuration follows:

· Operating System: Windows NT server version 4.0, SP 5

· <snip>

3.4 Business Site

The business site is used to house the hardware for our firewalls, email, development and test servers, workstations, print servers and supporting networking hardware. A locked enclosure shall house the firewall, email and print servers. A separate locked area shall house the development and test servers. A battery backup system shall provide 3 hours backup to all server equipment (except workstations) housed at the site.

The private connection between NOC and business site must provide sufficient bandwidth between application servers to prevent degradation. For this reason, business Internet traffic travels through the separate connection. Switches and routers are strategically placed to enable either 10 or 100 Mbit/sec connections between servers and clients. Static IP’s are used for the servers to maximize security and minimize dynamic allocation. Dynamic IP’s are used for all client workstations to minimize system administration overhead.

The business office houses the company intranet and PBX telephone switch.

Multiple servers will handle printers, dynamic IP assignment to workstations, email and connection to the Internet through a firewall.

All firewall software shall be configured and monitored by approved consultants or company personnel.

Application development software runs on high performance servers. The applications include web page design, database design tools, middleware application development tools, middleware applications, web server and database server. This development system should be considered a clean-room environment whereby the product under development has no chance to contaminate the production environment. Connection between server and workstation is handled through a network connection between UNIX servers and PCs using samba. An Internet connection separated by firewall software on a server connects the business site to the Internet.

Email is provided by internal applications. The firewall shall check the email addresses of all recipients for validity prior to granting the messages passage.

We will assign IP numbers using DHCP for workstations. We will use Windows NT Server to provide DHCP, email, authentication and printer server functionality. This server will reside at the business site.

See Appendix C for Business Site Network Diagram.

3.4.1 Telephone System

The business site houses our PBX telephone switches. The telephone system is answered automatically by an automated software system supplied by Lucent. A directory of personnel and telephone extensions is supplied to callers of the business telephone number (858)-638-0026.

Our outsource customer support vendor, service.com, provides <tbd 1-800-xxx-yyyy > telephone support for a limited amount of customer support.

3.4.2 Hardware

3.4.2.1 Switch

The required switch configuration is the following:

· Cisco 2912XL

3.4.2.2 Routers

The required router configuration is the following:

· Cisco 2610

· CSU/DSU

3.4.2.3 Hubs

The required hub configuration is the following:

Ø Cisco Catalyst 2924

3.4.2.4 Firewall

The firewall server shall be supported by a battery backup system capable of supplying power for 3 hours. The required firewall configuration is the following:

· Sun Ultra 10 Web Server

· 333 MHz processor

· 1GB memory

· 10 GB of disk space (highly dependent on user requirements)

· SVGA Video card

· Monitor (80 MHz, 1024 x 768 screen resolution)

· Mouse

· Keyboard

· UPS (Uninterrupted Power Supply)

· Ethernet network adapter (10/100 NIC card)

3.4.2.5 Development System

The development hardware exactly replicates the production equipment.

3.4.2.6 Primary Domain Controller

The PDC server shall be supported by a battery backup system capable of supplying power for 3 hours. Business users will store files upon this high performance hardware. The server shall support the following functionality for our users to use it efficiently:

· There shall be enough free disk space to contain DHCP, Printer and Domain controller software.

· There shall be enough free disk space to contain the Windows NT server operating system.

The required file server configuration is the following:

· Dell xj500 server

· 300 MHz processor

· 1GB memory

· 100 GB of disk space (highly dependent on user requirements)

· SVGA Video card

· Monitor (80 MHz, 1024 x 768 screen resolution)

· Mouse

· Keyboard

· UPS (Uninterrupted Power Supply)

· Ethernet network adapter (10/100 NIC card)

3.4.2.7 File Server

The file server shall be supported by a battery backup system capable of supplying power for 3 hours. Business users will store files upon this high performance hardware. The server shall support the following functionality for our users to use it efficiently:

· There shall be enough free disk space to contain the user files.

· There shall be enough free disk space to contain the system files software.

· There shall be enough free disk space to contain the Windows NT server operating system.

The required file server configuration is the following:

· Dell xj500 server

· 300 MHz processor

· 1GB memory

· 100 GB of disk space (highly dependent on user requirements)

· SVGA Video card

· Monitor (80 MHz, 1024 x 768 screen resolution)

· Mouse

· Keyboard

· UPS (Uninterrupted Power Supply)

· Ethernet network adapter (10/100 NIC card)

3.4.2.8 E-Mail Server

Business email software will execute on this high performance hardware. The email server shall support the following functionality to operate efficiently:

· There shall be enough free disk space to contain the email application software.

· There shall be enough free disk space to contain the Windows NT server operating system, the email software, and the email database.

The required email server configuration is the following:

· Dell xj500 server

· 300 MHz processor

· 1GB memory

· 100 GB of disk space (highly dependent on user requirements)

· SVGA Video card

· Monitor (80 MHz, 1024 x 768 screen resolution)

· Mouse

· Keyboard

· UPS (Uninterrupted Power Supply)

· Ethernet network adapter (10/100 NIC card)

3.4.2.9 Workstations

Business users require hardware capable of supporting their various application software. The workstations shall support the following functionality to operate efficiently:

· There shall be enough free disk space to contain application software.

· There shall be enough free disk space to contain the Windows operating system.

· The GUI portion of the software requires a screen resolution of 1024 x 768 pixels (large fonts) with a minimum color depth of 256 colors. An appropriate SVGA monitor shall be installed.

The required workstation configuration is the following:

· Dell xj500 computer

· 300 MHz processor

· 128 MB memory

· 10 GB of disk space (highly dependent on user requirements)

· SVGA Video card

· Monitor (80 MHz, 1024 x 768 screen resolution)

· Mouse

· Keyboard

· Ethernet network adapter (10/100 NIC card)

3.4.2.10 Printers

Business users require printers capable of supporting their various application software.

The required printer configuration is the following:

· Minolta 18 printer

· 64 MB memory

· Ethernet network adapter (10/100 NIC card)

3.4.3 Software

3.4.3.1 Database

Administration Tools

Image Server

FTP Server

Bug Tracker

Intranet Server

Bulk Load

The BulkLoad Access database (\\Phantom\Sharedfiles\dataEntry\BulkLoader\BulkLoad.mdb) is a Multi-User front end linked to the Shared BulkLoadData database which is the actual staging repository.

The QAStatus table is used to define the various steps of procedural review. As a company's listing is massaged, the QALevel (Items.ITMQALVL) is manually updated. The StagedItems Query will not pass an item to the MoaiBulkLoader Java application until the ContentQA Macro determines there are no fatal errors and the final QALevel has been reached. The final QALevel is defined by its QAStatus.QAISOK boolean being True.

The ContentQA Macro runs a series of Queries to check data fields and create records in an indirection table to link a given Owner/Seller (RejectedOwners) or Item (RejectedItems) with its’ Errors. The Errors Table has a field to indicate whether the error is a "show-stopper" (Errors.ERRISREJ) and whether it is "hidden" (Errors.ERRISINFO) from the list that shows up both in the bottom part of the data entry form and in a feedback error report organized by Seller. It also defines the error description, where the reasons WHY the data is needed is given.

We can add/alter the Errors Table items, add more QALevels, and create additional Queries to help filter out those Items needing action.

When we are bulk loading 10,000 items and the automatic email system that is set to send emails when items have been added, we don't want to send 10,000 emails when the bulk load process takes place.

The real event handlers detect a tag in the offering object that identifies that offering as being part of a bulk load process. This is done by placing some value in a field from the offering table that the event handler will read and bypass new listing emails.

Customer Entry

A temporary database was created to capture “customer data” prior to the availability of our anticipated facilities. The life expectancy of this database was “two weeks”. To the best of my knowledge, it is no longer in existence service

See “Octane” below.

Moai (Live Exchange)

There are currently problems associated with the Moai connections to the database. When we resolve this it will be documented.

Oracle

Please refer to 4.3.2.5.1 Installation, 4.3.2.5.2 Execution, 4.3.2.5.3 Maintenance, and 4.3.2.5.4 Verification, as these sections apply to the business suite, as well.

Octane

The ots0 instance is currently being backed up periodically on the ots0 server and on the DBAs workstation. No official schedule has been established, and automated procedures have not been implemented. Further, getting it off the disk and onto tape needs to be done, as well.

There is currently a difference between the instance on my machine and the one in production. The version the DBAs machine is 7.00.623, while production is 7.00.699. The only visible configuration difference is the code page used (437 vs. 1252); but there are periodic errors with “sort order” (32 vs. 52).

Until these differences are resolved, I do not plan to write the procedures. Getting the right file format to restore, or to send to service, has been tedious, at best.

3.4.3.2 Firewall

A dedicated server shall conduct Internet traffic between our business site and other Internet sites. The server shall run a single application, the firewall. Again, we have chosen Checkpoint’s Firewall-1 as the application of choice. It shall be configured to allow approved VPN and static IP addresses through. Remote users are allowed entry through the firewall if they install certificates on their workstations. The following is the configuration for the firewall.

<xxx insert configuration here>

It shall not prevent connections initiated at the business site through, to the Internet. This firewall shall allow FTP and TELNET protocols through, to the business site for only approved source static IP addresses. This firewall shall allow SMTP protocols through, to the business site for only our domain name and approved email addresses.

The firewall is also configured to announce the IP of our web server to the Internet.

· Operating System: Sun Solaris version 2.6

· <snip>

3.4.3.3 Web Page Monitor

· Operating System: Sun Solaris version 2.6

· <snip>

3.4.3.4 Web Page Server (phase 2)

· Operating System: Sun Solaris version 2.6

· <snip>

3.4.3.5 Application Server 1

· Operating System: Sun Solaris version 2.6

· <snip>

3.4.3.6 Staging Application Server 1

· Operating System: Sun Solaris version 2.6

· <snip>

3.4.3.7 ERP Server

· Operating System: Sun Solaris version 2.6

· <snip>

3.4.3.8 CRM Application Server

· Operating System: Windows NT server version 4.0, SP 5

· <snip>

3.4.3.9 CRM E-Mail Server

· Operating System: Windows NT server version 4.0, SP 5

· <snip>

3.4.3.10 Primary Domain Controller

· Operating System: Windows NT server version 4.0, SP 5

· <snip>

3.4.3.11 File Server

· Operating System: Windows NT server version 4.0, SP 5

· <snip>

3.4.3.12 E-Mail Server

· Operating System: Windows NT server version 4.0, SP 5

· <snip>

3.4.3.13 Workstations

· Operating System: Windows NT/98

· <snip>

3.4.3.14 Printers

· Server name: accounting

· <snip>

· Server name: engineering

· Server name: marketing

· Server name: hp5000

3.5 Outsource Site

--- describe san jose email, chat & telephone activity ---

3.5.1 Hardware

--- describe hardware connecting our sites ---

3.5.2 Software

--- software here ---

--- note which systems we can control from our business site ---

4. Policies

4.1 Responsibilities and Organization

The Operations Group (OG) shall be independent from the development organization, while still equivalent in importance. OG personnel shall be recruited and trained to form a high-quality OG organization to ensure that no conflict of interest can occur between engineering, test, and quality assurance groups. OG shall remain independent and at the same time have the authority to provide recommendations concerning the technology, quality, and readiness of company systems.

4.1.1 Responsibilities

O&M activities shall be conducted by the OG group.

4.1.2 Required Commitment and Support of Management

The following is management’s commitment to the OG organization:

Ø OG shall have the authority and support of management to manage company hardware, operating systems, internal email, telephone and networking systems.

Ø Management shall commit to adequate OG resources, including:

Ø Personnel (the correct skill mix and qualifications, not only entry level)

Ø Equipment (proper test equipment to perform independent testing activities at the <defunct> facility)

Ø Software

Ø Funding (allocation of hours and dollars based on the processes and methodology outlined in this document)

Ø Time (adequate schedule time to perform a thorough and complete actions)

Ø Training (sufficient training resources to enable the group to complete the OG objectives)

Ø Management shall commit to necessary startup costs required to put the minimum required processes and methodologies in place.

4.1.3 Organization Staffing Criteria and Guidelines

The following criteria and guidelines shall be used to help build and staff an OG organization:

Ø Organization size: Many factors help determine the number of OG personnel required for an organization, including:

Ø Type of work

Ø Project complexity

Ø Number of internal/external interfaces along with complexity factors

Ø Historical measurements from past projects

Ø Career development and growth, which includes training: Proper training for personnel ensures career enhancement opportunities and professional growth.

This table identifies the organization and responsibilities, as well as those individuals that will support the O&M effort.

	Core Team:
<snip>		Director of Engineering
David Russell		Database Administrator
<snip>		System Administrator
<snip>		Network Administrator
<snip>		Director of Operations
<snip>		Webmaster

	Committed Resources:
David Russell		Database Administrator
<snip>		System Administrator
<snip>		Network Administrator
<snip>		Director of Operations

	Supporting Resources (as required):
<snip>		Software Engineer
<snip>		Director of Engineering
<snip>		Software Engineer
<snip>		DB Architect
<snip>		QA Lead
<snip>		Software Engineer
<snip>		Lead Software Engineer

	Management:
<snip>		CTO
<snip>		VP
<snip>		VP

4.2 Philosophy

4.2.1 Overview

The strategy for ensuring a complete and thorough O&M effort is to provide early and continued involvement throughout all aspects of company growth. Another key strategy is the ability to test thoroughly and properly at each deployed information system, within budget and schedule constraints. To accomplish this, OG shall use the team approach. That is, at least one member of the department shall provide support during each phase of system analysis and deployment to ensure consistency and completeness before proceeding to the next phase of activities.

4.2.2 Adherence to <defunct>-Established Policies and Procedures

Specific O&M policies and procedures shall be put in place to ensure that a consistent quality of effort is performed. Standards and guidelines shall be used as a common starting point and can be modified based on business requirements.

5. Procedures

5.1 Interfacing with Other Groups and Organizations

During execution of O&M procedures, the OG organization will interface with other departments, as well as with customers. These activities all interrelate and have dependencies. The OG organization interfaces with these groups by not only providing input or information to them, but by receiving output from them as well. At a very high level, the interfaces are discussed in the following paragraphs.

5.1.1 Software Development Interface

OG will interface with the software development organization in two different modes. The first mode is that of the OG group’s support of the software development group from the beginning of the software development process through delivery of web site products. This support includes:

Ø Ensuring hardware and system implementation of the requirements

Ø Reviewing software documentation

Ø Supporting milestone and peer reviews

Ø Supporting testing and reviewing results (as required)

The second mode is that of software development group supporting the OG group. This support is primarily related to the following:

Ø Providing technical inputs to the project deployment activities as documented in the Software Test Plan

Ø Working closely with the OG group to identify the items required to execute its duties

Ø Supporting the OG group in the execution of the system testing activities

Ø Answering software functionality questions along with investigating and fixing problems that occur during deployment

5.1.2 SCM Interface

The OG organization’s primary interface with SCM is for the following:

Ø Establishing and maintaining the hardware environment, configuration, and baseline for all software development and test activities

Ø Ensuring the OG group's compliance to SCM policies and procedures

In addition, OG provides libraries of automated recovery scripts, regression playback tests, automated test tool products used for testing, test results, etc., to SCM for control. OG will also require support from SCM when it comes to Trouble Report (TR) generation and tracking. That is, SCM will provide a problem-tracking mechanism or tool to be able to document, report, track progress and resolution, as well as provide closure status during and after re-deployment.

5.1.3 Support Staff Interface (Documentation/System Administration/Training)

The OG group will interface with the documentation support staff and training representatives throughout the execution of these procedures.

Documentation support will help ensure consistent, quality documentation during the development and revision of OG documentation.

The OG group’s interaction with the training group will address the training needs and requirements of the OG staff. This training can include training in OG planning, procedure writing, execution and analysis, reporting, etc. OG’s interface to training can also entail turning the training group inputs into possible training. The OG group may also provide input into the training course content.

5.1.4 Project Management Interface

Interfacing with project management will occur, at a minimum, on a weekly basis. OG will provide status for the weekly activities to the functional manager and a copy to the Software Lead (SL) as appropriate. This is an independent, unbiased assessment of the current state of activities. As <defunct> proceeds through product development, OG support responsibilities increase. OG will interface with the SL on a more frequent basis by providing status, progress, issues, etc.

5.2 Fault Management

5.2.1 Surveillance and Control

Every element of the website shall be configurable from the business site. All routers, servers, switches, and software shall allow remote administration from a designated static IP address located within the business site. All server consoles and applications shall authenticate user login against an approved list of users. The approved list of static IP’s and user names shall be stored in a safe and secure location at the business site. If this list is required, in binary form, for proper operation of software, it shall be encrypted. Under absolutely no circumstances shall the co-location or business site software be configurable from outside the firewall.

All firewall software shall be configured and monitored by approved consultants or company personnel.

The areas of responsibility shall include (but not limited to):

Ø distributed monitoring, with delegation of monitoring functions to local environment

Ø early detection of possible problems arising from the local environment

Ø automatic alert (trap) generation and event handling

Ø alert and event filtering capabilities to tune the level of information

Ø automation of operational procedures

Ø centralized management of distributed log information for problem diagnostics

Ø efficient access to catalogued information for corrective actions

Ø reduced management bandwidth usage over WAN connections

Ø code-less integration with the enterprise management system

Ø extensibility, allowing to instrument the application for manageability

5.2.2 Alarm Handling

5.2.2.1 Database

In the near future, all Oracle instances will be monitored by Oracle Enterprise Manager (OEM) and the Diagnostics Pack. OEM will run on a standalone NT workstation located in the Database Architect’s area. This referred to as the “Management Server”. From the management server, intelligent agents and data gatherers will be directed to monitor system and database activity. These agents are designed to be host independent, so that the failure of a host will not prevent the agent from reporting.

A comprehensive set of events and jobs will be defined to notify DBAs when problems arise. If a listener or datagather is lost, or a database or host crashes, the Management Server will send a message to the DBAs beeper.

Threshold events will also be designed to notify DBAs of potential problems—before they occur, such as files that have grown beyond planned sizes. Such events give DBAs adequate time to take corrective action before it too late.

5.2.3 Trouble Detection

5.2.3.1 Database

Oracle Diagnostics will monitor the performance statistics of both Oracle databases and the UNIX system. Tuning and performance parameters will be graphed in real time to provide comprehensive information on system performance, so that preventative action can take place.

5.2.3.2 What’s Up Gold

5.2.3.3 HP OpenView

5.2.4 Trouble Correction

Figure 3 – Failure Restoration Flow Chart

5.2.5 Test and Acceptance

5.2.6 Network Recovery

5.2.7 Work Order Handling

5.2.8 Escalation Procedures

5.3 Configuration Management

5.3.1 System Turn-up

5.3.2 Network Provisioning

5.3.2.1 Installation of Solaris Operating System

Insert the Solaris 2.6 CD in the drive. At the boot prompt type boot. The following configuration settings need be done for the installation setup. The host name, ip address, subnet mask, default gateway, the nameserver setup and search order, the time zone set to PDT, the power save mode set to be disabled and permanently written to the configuration. The disk shall be partitioned to have a 1GB root slice, 2 GB /opt slice, 2 GB /export slice, 1.5 GB / var slice and 2 GB swap space.

5.3.2.2 E450 Hardware Setup

The E450 houses a max of 4GB memory and 2 400MHz Sparc CPUs. We have a configuration of 1 GB memory, 1 400MHz CPU, 4 9.1GB disk drives, 2 Fast Ethernet adaptors and 2 differential SCSI adaptors. The unit at the business site is rack mountable while the unit at the co-location site is set on shelves. The base unit comes with 1 Fast Ethernet adaptor, 1 CPU and 512 MB memory.

Following the attached diagrams detailing the specifications of the E450, remove the side panel to gain access to the PCI bus. Install the differential SCSI adaptors in Slots 1 and 2. The network adaptors shall be in slot 4 and 5. Install the memory SIMMs to a total of 1GB. After removing the plastic covers from the SCSI port, install 2 hard disks in Slot 0 and 1 in the lower drive bay. Next install the other 2 hard drives in Slots 0 and 1 in the upper drive bay. Solaris shall be installed the disk in Slot 0, lower bay and shall mirror using VM to the disk in Slot 0, upper bay. The disk in Slot1, lower bay shall contain 1 8.5 GB slice for housing the Oracle binaries and shall mirror to the disk in Slot 1, upper bay.

5.3.2.3 E250 Hardware Setup

See 5.3.2.2 - E450 Hardware Setup

5.3.2.4 A1000 Hardware Setup

The A1000 is a single controller RAID unit that can house 12 drives of a combination of 9.1GB, 18 GB or 36 GB drives. We have 12 - 9.1 GB drives. It has 2 drive groups with each drive group comprising of 6 disks. They are referenced as [1,0], [1,1], [1,2], [1,3], [1,4], [1,5] [2,0], [2,1], [2,2], [2,3], [2,4], [2,5]. [1,0], [1,1], [1,2], [1,3] are used for the MOAI partition (sic); [2,0], [2,1], [2,2], [2,3] are used for the Oracle partition (sic); [2,4], [2,5] are used for the MOAI redo logs; [1,4] is used for the Oracle redo logs; [1,5] is the designated hot spare disk.

Two A1000 units are setup with the above configuration.

The third A1000 is 10 - 9.1 GB disks. [1,5] and [2,5] are empty and do not house a disk drive. [1,0], [1,1] and [1,2], [1,3] are setup as 2 LUNs for the image storage. [2,0], [2,1], [2,2], [2,3] are setup as 4 LUNS and used as a scratchpad area. [1,4] and [2,4] are the designated hot spares.

The first A1000 is labeled as the Eq_main array, the second A1000 is labeled as Eq_mirror array and the third A100 is labeled as Image array. The left SCSI port of each A1000 is connected to the left port on the differential SCSI adaptor in Slot 1 and Slot 2 in the E450 and E250. The right port on each A1000 is connected to the left port on the differential SCSI adaptor in Slot1 and Slot 2. The left SCSI port of the third A1000 is connected to the right port of the differential SCSI adaptor in Slot 1 in the E450. The right SCSI port of the third A1000 is connected to the right port of the differential SCSI adaptor in the E250.

Figure 4 – SCSI Connections between 250, 450, and A1000

RAID 0 configuration shall be setup to provide stripping and VM shall be configured to provide mirroring.

5.3.2.5 Tape Library (after test env. Stable)

5.3.2.6 File System Layout And Sizes

5.3.2.7 Discuss Vm Installation

5.3.2.8 Discuss Vxfs Installation

5.3.2.9 Oracle Installation

5.3.2.10 Live Exchange Installation

Except for the Oracle updates, login as root to perform these functions.

Note: all LiveExchange files were owned by root with group other.

The goal is to change the protection on the 3 required directories to rw on world, permitting the developers to install their own class files in the following directories:

/opt/LiveExchange_3.0/public_html/auction

/opt/LiveExchange_3.0/public_html/servletclasses

/opt/LiveExchange_3.0/server/classes/com/<defunct>

An initial test indicates that a developer can own the class file and the system still works (i.e. it is probably not necessary for the root user to own the class files).

Edit properties files for LiveExchange

/opt/LiveExchange_3.0/ConfigServer/Properties/moai.properties

Change 1:

From:

#moai.liveexchange.msp.documentRoot=/opt/LiveExchange_3.0/public_html/C2C

To:

moai.liveexchange.msp.documentRoot=/opt/LiveExchange_3.0/public_html

Changes 2-6:

From:

#moai.liveexchange.msp.verbose=false

#moai.liveexchange.msp.develop=false

#moai.liveexchange.msp.keepGenerated=true

#moai.liveexchange.msp.debug=false

#moai.liveexchange.msp.useRealTimeApplet=false

To:

moai.liveexchange.msp.verbose=true

moai.liveexchange.msp.develop=true

moai.liveexchange.msp.keepGenerated=true

moai.liveexchange.msp.debug=true

??? check out

moai.liveexchange.msp.useRealTimeApplet=false

Change 7

??? check out

From:

moai.liveexchange.msp.pageCheckSeconds=10

To:

moai.liveexchange.msp.pageCheckSeconds=1

Notes: the current email addresses that will be formatted into system generated emails are:

moai.liveexchange.email.fromName=<defunct>@<defunct>.com

moai.liveexchange.email.fromAddress=<defunct>@<defunct>.com

/opt/LiveExchange_3.0/server/weblogic.properties

Changes 1-5:

weblogic.httpd.register.classes=weblogic.servlet.ClasspathServlet

#weblogic.httpd.register.classes=weblogic.servlet.ClasspathServlet

weblogic.allow.execute.weblogic.servlet.classes=everyone

#weblogic.allow.execute.weblogic.servlet.classes=everyone

weblogic.httpd.register.servlets=weblogic.servlet.ServletServlet

#weblogic.httpd.register.servlets=weblogic.servlet.ServletServlet

weblogic.httpd.servlet.classpath=/opt/LiveExchange_3.0/public_html/servletclasses

#weblogic.httpd.servlet.classpath=c:/myservlets

weblogic.httpd.servlet.reloadCheckSecs=1

#weblogic.httpd.servlet.reloadCheckSecs=10

Extract source from VSS:

MSP

From <defunct>Development\Msp

Copy To: /opt/LiveExchange_3.0/public_html/auction

Place top level page, index.msp in /opt/LiveExchange_3.0/public_html

Jar files

From <defunct>Development\lib

Placed in /export/home/projects/cots/jars for compilation

Java – package com.<defunct>

From <defunct>Development\com

Copy To: /export/home/projects

All .java files are compiled here and the class files are directed to the directory /opt/LiveExchange_3.0/server/classes

Note: The <defunct>.properties file that was checked into the <defunct>Development/com/<defunct> directory must be copied to the /opt/LiveExchange_3.0/server/classes/com/<defunct> directory. This file contains information that is set in SiteMap.class.

Email Templates

From <defunct>Development\Email Templates

Copy To: /opt/LiveExchange_3.0/emailTemplates

Servlets

From <defunct>Development\ServletClasses

All .java files are compiled and the class files are directed to the directory /opt/LiveExchange_3.0/public_html/servletclasses

Class Builds:

The following sample make file makes the class and puts the class file out to the correct directory, /opt/LiveExchange/server/classes/:

# makefile for setup program

CL_DEST = /opt/LiveExchange_3.0/server/classes

COTS_DIR = /export/home/projects/cots/jars

SRCS = \

<defunct>User.java

OBJS = ${SRCS:.java=.class}

JAVAC = /usr/java1.2/bin/javac

JOPTS =

CP = .:$(COTS_DIR)/servlet.jar:/opt/LiveExchange_3.0/server/weblogicaux.jar

:/opt/LiveExchange_3.0/server/classes

all: install

install: ${OBJS}

# Suffix rule for all java files

.SUFFIXES : .java .class

.java.class:

${JAVAC} -classpath ${CP} -d $(CL_DEST) ${JOPTS} $<

Oracle Updates:

Create file events.sql:

UPDATE MoaiOfferingFormat

SET offeringEventAdapterClass = ‘com.<defunct>.event.<defunct>OfferingEventAdapter’

WHERE MoaiOfferingFormat.name = ‘Fixed price’;

UPDATE MoaiOfferingFormat

SET offeringEventAdapterClass = ‘com.<defunct>.event.<defunct>OfferingEventAdapter’

WHERE MoaiOfferingFormat.name = ‘English’;

SELECT name, offeringEventAdapterClass FROM MoaiOfferingFormat

WHERE MoaiOfferingFormat.name = ‘Fixed price’

OR MoaiOfferingFormat.name=’English’;

UPDATE MoaiConfigParam

SET value = ‘com.<defunct>.event.<defunct>UserEventAdapter’

WHERE MoaiConfigParam.name = ‘moai.liveexchange.server.UserEventAdapterClass’;

SELECT name, value FROM MoaiConfigParam

WHERE MoaiConfigParam.name = ‘moai.liveexchange.server.UserEventAdapterClass’;

I created two files in /export/home/oracle/wendy_sql to automate the oracle updates:

doit.sh and events.sql.

To run the commands, do:

(a) Login as oracle user

(b) cd wendy_sql

Execute the commands one of the following ways:

(1) Sqlplus madmin/madmin @events

(2) sh doit.sh

Starting Up the LiveExchange Server:

The following line must be added to the startup.sh file in the /opt/LiveExchange_3.0 directory:

export CLASSPATH=/usr/java1.2/jre/lib/rt.jar:/opt/LiveExchange_3.0/server/lib/we

blogicaux.jar:/opt/LiveExchange_3.0/server/classes:/opt/LiveExchange_3.0/server/

mssql4classes:/opt/LiveExchange_3.0/server/lib/activation.jar:/opt/LiveExchange_

3.0/server/lib/mail.jar:/opt/LiveExchange_3.0/server/lib/xml.jar

To start the server:

nohup ./startup.sh &

Stopping the LiveExchange Server:

ps –ef | grep jre

The command line looks like /…./jre …. ???

Find the process id and

Kill –9 ‘pid’

Moai Email:

Standard email subject fields can be changed through the admin tool. No changes have been made to date.

5.3.2.10.1 How to start MOAI LiveExchange

MOAI LiveExchange is the auction software we use at <defunct>.com. We run three primary systems: Development, Test, and Production. The passwords needed to log in to the three systems differ, but the process for starting and stopping the software is the same for all three platforms.

To start the MOAI LiveExchange server, do the following:

· Log in to the system as the user 'moai':

· login: moai

· Password:

This login should drop you directly into the home directory used by the LiveExchange software. You can confirm this:

$ pwd

/opt/LiveExchange_3.0

Review the settings for the file named moai.server:

# ls -l moai.server

-rwxr--r-- 1 root sys 3594 Mar 14 16:50 moai.server

· If you head this file, you will note the following comment:

$ head moai.server

#!/bin/sh

# ----------------------------------------------------------------------------

# $ Header: $

# ----------------------------------------------------------------------------

# moai.server

# Start / stop / restart the MOAI LiveExchange server

# This file should have uid root, gid sys and chmod 744

If these settings are not made the server will not be able to run on port 80, the default port for the http protocol.

Become the super user:

$ su root

Password:

If the server is already running, shut it down:

# ./moai.server stop

It sometimes happens that this attempt to shut down the system fails. [CLM Note: show an example of this by forcing an error] If this happens, you must kill the process. To do this, find the running Java Virtual Machine and kill it:

# ps -ef | grep java

root 751 690 0 Jan 24 ? 2:22 jre -nojit -noasyncgc -cp /opt/VRTSvmsa/vmsa/java -Dvrts.codebase=/opt/VRTSvmsa

root 780 690 0 Jan 24 ? 44:03 jre -nojit -noasyncgc -cp /opt/VRTSvmsa/vmsa/java -Dvrts.packageName=SOL -Dvrts

root 18273 18104 0 10:37:41 pts/5 0:00 grep java

moai 27522 1 0 Mar 31 ? 9:55 /opt/LiveExchange_3.0/server/jdk/bin/../bin/sparc/native_threads/java -classpat

The process you are looking for is the one that starts with /opt/LiveExchange, in the example above it is process ID 27522. Issue the command

kill 27522

That should remove the process.

Start the LiveExchange server:

# nohup ./moai.server start

It is very important to use nohup when starting the server. If you do not do this, the process will end as soon as you close the window in which you started it.

5.3.2.11 Network Peripherals Setup

5.3.2.12 Router Setup on Business Site

5.3.2.13 Router Setup on Pt To Pt Between Co-Lo and Business Sites

5.3.2.14 Router Setup on Pt To Pt Between Co-Lo and Abovenet

5.3.2.15 Router Setup on Connection To Isp

5.3.2.16 Static Routes Between Co-Lo And Business Sites

5.3.2.17 Switch Setup And Configuration

5.3.2.18 Firewall Setup And Configuration For Business Site And Co-Lo Sites

5.3.2.19 Business Site Vpn Setup

5.3.2.20 Partner Access Vpn Setup

5.3.2.21 Remote Admin Of Co-Lo Site Firewall By Business Site Firewall

5.3.2.22 Business Email Setup and Configuration

5.3.2.22.1 Install Exchange Server 5.0

Execute startup from Exchange Server CD.

When the setup dialog appears, select the Complete/Custom button.

When the Complete/Custom dialog appears, check box all options and press Continue.

When the CD-Key dialog appears, enter the CD Key. Press OK when done.

When the Licensing Mode dialog appears, select the Per Seat radio button, press Continue.

Select Create a new site radio button. Complete the fields for Organization Name and Site Name. Enter <defunct>.com and DARKSIDE, respectivily.

Enter the account password for the Exchange Administrator, and then select OK.

Files and services will now be copied to the system. Registry changes will also be made. This should take about 8 minutes before the completion dialog appears. You are presented with two choices: Run Optimizer and Exit Setup. Choose Exit Setup.

Next, update Exchange with Exchange Service Pack 2. This should take about 5 minutes.

Next, run Optimizer from the Exchange program menu.

When the Performance Optimizer dialog appears, check box 101-250 Users on this server, Private Store, Public Store, Multiserver, and 100-999 Users in organization. All other boxes are either blank or 0. Select Next.

When the next Performance Optimizer dialog appears, you will be asked to designate the files locations for the server. Change all logs and databases to the D: drive in the same recommended directory.

The next Performance Optimizer dialog allows you to restart the services. Check box the Do not restart these services then select Finished.

Open the Control Panel and select Services. Select each of the following services in turn, click on Startup, and change the Startup Type to Automatic:

· Microsoft Exchange Directory

· Microsoft Exchange Information Store

· Microsoft Exchange Message Transfer Agent

· Microsoft Exchange System Attendant

Install Internet Mail Service.

From MS Exchange Administrator, select File | New Other | Internet Mail Service.

· Choose appropriate machine on which to install the Service (EXSERVER).

· Choose “Route all mail through a single host”.

· Allow all Internet addresses (typical).

· Choose appropriate mail extension (@<defunct>.com).

· Disable Circular logging.

On Internet Mail Service connector, under Properties:

· General Tab: computername = EXSERVER

· Connected Sites Tab: nothing to enter

· Address Space Tab: Type: SMTP Cost=1

· Delivery Restrictions Tab: Accept from all; reject from none.

· Diagnostic logging tab for MS Exchange IMC service: SMTP interface events to minimum; all others none.

· Internet Mail Tab: admin mailbox=administrator; send attachments using plain text MIME; char set=MIME/Western Euro non-MIME=US ASCII

· Dial Up Connections Tab: nothing to enter

· Queues Tab: nothing to enter

· Routing tab: reroute incoming SMTP mail-mail sent to <defunct>.com. route to inbound

· Security Tab: nothing to enter

· Connection Tab: transfer mode=inbound and outbound; advanced button=take default.

5.3.2.22.2 Disaster and Recovery Planning

This section defines transaction logs and checkpoint files and their respective roles in backup and recovery, circular logging, and transaction logs in playback. First, the Exchange client sends a message to the server, the server receives it, executes transactions that must take place in memory, and almost instantly writes those transactions to a log file. After a certain interval, the transaction is written out through the information store or the database file, the PRIV.EDB or the PUB.EDB.

In other words, for performance and reliability reasons, the transactions are written to the sequential log files first and then to the database files. This means that for every transaction written out to your database file, there is a copy in a log file, which can be played back into your database file in case of a crash. That’s the key benefit of transaction logging.

One useful characteristic of an Exchange Server transaction log is its size: whether full or empty, it usually is 5 MB. Therefore, if you see a log file of some other size, you can assume it is corrupt. The current transaction log is always called EDB.LOG. When it is filled, it is renamed to edb0001.log, EDB0002.LOG..., and a new EDB.LOG is created. In addition, each transaction-log file contains a signature that must match the signature of the corresponding database file. If these signatures do not match, the corresponding service fails on startup and the event log contains a Jet-level error message, indicating an invalid log signature or an invalid database signature.

The checkpoint file is an optimization, enabling the service to track which transactions have and have not been committed to the database. This file is called EDB.CHK, and for the directory service, it resides in the DSADATA directory. For the information store service, it resides in the MDBDATA directory. Again, if you run performance optimizer, the location of this file may vary. Every time you commit a transaction to the database file, the checkpoint file is updated.

Circular logging is a very important concept for disaster recovery. When circular logging is turned on, it saves storage by preventing the continuous buildup of transaction-log files on your drive. The downside, of course, is that with circular logging, incremental and differential backups do not occur and, therefore, are not available in case of a crash. Note that circular logging is the default setting in Exchange. If you do not want it, you can turn it off through the admin program.

Here’s how these transaction-log files and checkpoint files work for recovery. With all your transactions in a transaction-log file and the checkpoint file indicating what transactions have been committed to the database, the service scans the checkpoint files to find the last transaction committed to the database. The service then scans the transaction logs to find the transactions that are not yet committed to the database and writes them to it. This process occurs automatically when you start the service or when you’ve restored an online backup.

Microsoft Exchange classifies backups as either online or offline. An online backup is made while the Exchange services are running. To back up the data while the services are running, you need an Exchange-aware backup program, such as NETBACKUP. Such program back up data logically, that is, all the data related to the information store and all the data related to the directory service.

Off Line Backup

An offline backup is a normal file-level backup made with services stopped. Any backup software can perform an offline backup. However, when you restore, an offline backup does not automatically play through the log files, as does its online counterpart. For this reason, Microsoft does not recommend an offline backup for daily backups. Nonetheless, an offline backup is essential when online backups fail.

Online Backup

Exchange supports four kinds of online backups: normal or full, copy, incremental, and differential. A normal backup backs up your database files and then the transaction-log files; then it deletes the transaction-log files from the directory. This means you can have circular logging disabled, because your backup software deletes the log files. So if you’re performing regular backups, you won’t have a problem with log files filling up your drive. To restore a normal backup, you need only restore your last normal backup set and start the service.

A copy backup is similar to a normal backup except that it doesn’t purge the log files on your drive and doesn’t update the backup context in the database files. Thus, it is practical when you don’t want to disturb your normal backup schedule, but you do want to back up your data.

An incremental backup works only on the log files and, thus, only when circular logging is disabled. Like a normal backup, incremental backup also purges log files after backing them up. So it provides yet another way to rid log files from your drive without compromising recoverability. To restore an incremental backup, you must return to your last normal backup set, which contains your database files. Restore those database files, restore every incremental backup set made after the normal backup, and then start the service. Note that you should not start the service until you have restored all the backup sets. Otherwise, any logs restored after the backup set will not be played forward.

Like an incremental backup, a differential backup also works on log files, so to use it, you must have circular logging disabled. Unlike an incremental backup, however, a differential backup does not delete the log files. To restore a differential backup set, return to the last normal backup and restore your differential backup set, which contains the entire log files generated after your last normal backup. As with incremental backup, do not start the service until you have restored all the backup sets.

* Online backup is being implemented on the EXSERVER. A normal backup is done on Friday and a differential backup Monday through Thursday.

Exchange Server 5.5 Editions
Exchange Server 5.5 comes in two editions, Standard and Enterprise. EXSERVER is a standard edition, which include the following components:

· Exchange Server 5.5

· 16GigaByte database limitation

· Microsoft Outlook® 2000 client

· Microsoft Mail Connector

· Internet Mail Service (formerly Internet Mail Connector)

· cc:Mail Connector

· Exchange Connector

· Notes Connector

· Active Server Components (formerly Web X)

· Internet News Service (formerly NNTP)

· Microsoft Visual InterDev® integrated Web application development system

· An Exchange Server 5.5 Enterprise Edition contains the same components as Standard Edition, plus:

· Unlimited storage

· X.400 Connector

· IBM OfficeVision/VM/SNADS Connectors (requires Microsoft SNA Server)

· Microsoft Cluster Server support (requires Microsoft Windows NT® Enterprise Edition).

To migrate from a standard edition to an Enterprise edition will require a new Exchange server software installation.

Pricing and Licensing Offers
A Server License is required for each installed server product. The Server License grants the customer the right to run Microsoft server software on a single server (for this purpose, a server is defined as having up to four processors). This license may be purchased through full package products, Microsoft License Packs, the Microsoft Open License program, or the Microsoft Select program.

Microsoft Exchange Client Access Licenses (CALs) are required for any client software or application to connect to a Microsoft Exchange Server. CALs can be purchased for either five or 20 clients to access the services of Exchange Server. This license is not included with Microsoft Windows® 95 or Microsoft Office 97. Microsoft Exchange Client Access License Upgrade with 25 CALs is also available. This package is for customers who wish to upgrade their CALs from Microsoft Mail or from any competitor product to Exchange Server 5.5. It includes 25 CALs.

* Currently we have 100 CALs on our EXSERVER.

Full Product Offers	Part Number	Estimated Price
Exchange Server Standard Edition with Five Client Access Licenses (CALs) This package includes all the components necessary to install a single Exchange Server, as well as the Outlook 2000 client, Exchange Connector, Microsoft Mail Connector, Internet Mail Service, Notes Connector, cc:Mail Connector, Active Server Components, Visual InterDev, and the Internet News Service. This server can be configured to communicate with other X.400 servers by acquiring the necessary connectors. This package also includes five CALs. CD-ROM media only.	312-01070 Replaces: 312-00690	999.00
Exchange Server Standard Edition with 25 CALs This package includes all the components necessary to install a single Exchange Server, as well as the Outlook 2000 client, Exchange Connector, Microsoft Mail Connector, Internet Mail Service, Notes Connector, cc:Mail Connector, Active Server Components, Visual InterDev, and the Internet News Service. This server can be configured to communicate with other X.400 servers by acquiring the necessary connectors. This package also includes 25 CALs. License only.	312-01072 Replaces: 312-00691	2,129.00
Exchange Server Enterprise Edition with 25 CALs This package includes all the functionality of Exchange Server Standard Edition, plus the Microsoft X.400 Connector. Includes 25 CALs. CD-ROM media only.	395-01326 Replaces: 395-00955	3,549.00
Exchange Server Enterprise Edition with 50 CALs This package includes all the functionality of Exchange Server Standard Edition, plus the Microsoft X.400 Connector. Includes 50 CALs. CD-ROM media only.	395-01327 Replaces: 395-00957	4,859.00
Client Access License with Five CALs License for five clients to access the services of Exchange Server. License only.	381-00852 Replaces: 381-00297	369.00
Client Access License with 20 CALs License for 20 clients to access the services of Exchange Server. License only.	381-00850 Replaces: 381-00295	1,149.00
Microsoft Exchange X.400 Connector This package provides all the software needed to connect Exchange Server to X.400 systems and to use X.400 as a communications backbone to connect with other Exchange organizations. 3.5" media.	396-00123 Replaces: 312-874v400	999.00

5.3.3 Auto-discovery

<xxx tbd>

5.3.4 Backup and Restore

A sun netra t1 server chewy acts as the netbackup master server with tatooine, coruscant, naboo, ots0 and ots1 as clients. Two sets of 5 tapes are maintained. One set is used for incremental backups. The second set is used each Saturday for full backups. Every week, we shall test the quality of the backups by executing a restore in a test area.

The tape array unit is an ATL Powerstor 200 model with 1 DLT 4000 tape drive and 8 cartridge drives. It has a single ended SCSI adaptor and shall be connected to the netra. Tatooine has a total of 89GB. This will fit in 3 DLT tapes with compression enabled.

A netbackup class shall be created to do a complete backup. Oracle database extensions shall backup onto a separate tape. Oracle hotbackups shall be written to /work/backup and the remote copied to the business site which will be indexed for 1 week.

Daily data backups shall be performed by automated tape backup equipment attached to the application servers. Automated tape backup shall be performed on both the co-location application server and the business application server using separate tape backup equipment. These tapes shall be retrieved from the tape unit every seven days and stored in a fireproof safe. New, pre-formatted tapes shall replace the retrieved tapes. One year of tapes shall be retained.

The incremental tape backup method shall be used for each backup day. Each night, a complete hot backup is taken of all tablespace datafiles, archived redo logs, and the control file. All files are compressed to save space. In addition to the hot backups, full database exports are run following each hot backup. The full database exports are supplemental backup protection and enable the databases to be reconstructed. These files are written to a work area on each server and then backed up by the system administrator to tape.

Although many non 7 x 24 firms use incremental backups of the Oracle datafiles, such a strategy is inappropriate for the Production instances at <defunct>.com, due to the increased time of recovery and the extra downtime. We must be able to restore the files as quickly as possible, without the need to switch tapes and apply incremental backups. Restoring datafiles from incremental backups would add many hours to the database recovery time.

It is appropriate, however, to perform a weekly backup of the mount point for the each database. Backing up from the point mount captures both the Oracle binaries and the datafiles. Therefore, each week, a complete backup will be taken of the entire mount point for all Oracle databases, with the exception of the Vision database on Coruscant. (Vision in an example ERP database that is only run periodically).

If the time required to do the full weekly backups becomes excessive for any one day, the full backups of the mount points will be rotated during the week to reduce the time required on any day to do full backups. For example, the mount point backup of Moai Production could be performed on Sunday, while Oracle ERP Production could be performed on Monday.

These backup procedures are for the short-term, and will be replaced with Veritas NetBackup and Oracle Recovery Manager. Eventually, in Phase II, as transactions pick up and downtime becomes even more expensive, a weeks worth of the full mount point backups and the daily hot backups of tablespace datafiles, archived redo logs, and the control files could be stored on disk (in addition to tape) so that most recoveries can take place without the time required to restore from tape.

Once per month, a full database backup shall be performed and kept with the tape backup library. Data recovery shall be tested on each tape unit once per week, according to configuration management policy currently in effect. Data recovery shall be tested once per month.

5.3.4.1 Overview of Oracle Backup and Recovery

When the archivelog feature of Oracle is enabled, the database makes a copy of every online redo log after that log fills, so data recovery can occur to the point in time of database failure.

A clear distinction needs to be drawn between transactions and databases. A transaction in Oracle is made permanent with the commit statement, while transactions are undone with the rollback statement. Some people believe you can do something similar to a database. You can rollback a transaction, but no such commands exist for “rolling back” a database.

In order for an archived recovery to occur, a copy of the operating system files that comprise the database at a prior point in time must first be available. Then, from those files, commands are issued to recover the database. The archived logs are typically applied to the database until the last committed transaction. Recoveries prior to the last transaction are called “point in time” recoveries and must go through a similar process for recovery.

A mount point recovery typically is needed when the Oracle binary files become corrupted, an applied binary patch needs to be undone, or other similar file is lost.

Copies of the archived redo logs must be available for an archived recovery to occur and must be backed up by the system administrator as described previously. If no backup occurs, the database cannot be recovered from archived logs.

Every tape will be clearly labeled with the date of the backup. If the tape is for a special backup, it will be clearly labeled as such and must be removed from the tape queue and replaced with another blank tape. Otherwise, the backup that night will overwrite the special backup.

Procedures and Commands

The detailed commands and procedures to recover a database depend on the circumstances of the problem and are beyond the scope of the document. The procedures are described in the Oracle8 Backup and Recovery Guide. When Veritas is implemented, a series of scripts will be designed to facilitate typical problems.

Database Directories

The following directories (and below) should be backed up nightly:

On Tatooine:

/u07/oradata

/work02/exports

On Leai:

/u05/oradata

/work02/exports

On Skywalker:

/u03/oradata

/work01/exports

On Coruscant:

/u02/app/oraprd/admin/PRD/arch

/work/backup

The following directories (and below) should be backed up weekly:

On Tatooine:

/var/opt/oracle

/u01/app/oracle

On Leai:

/var/opt/oracle

/u01/app/oracle

On Skywalker:

/var/opt/oracle

/u01/app/oracle

On Coruscant:

/var/opt/oracle

/u02/app

/u03/app

/u04/app

This list does not include the Oracle "datafiles" which are associated with database tablespaces. Please also note, occasionally there will be special tapes that you must keep longer -- for instance, the two sets you are keeping for us to restore /u03 and /u04 on Coruscant (Oracle Financials, VIS and TST instances). These mount points contain "app" and "oradata", the Oracle libraries and the instances datafiles.

The backup start times are as follows:

On Tatooine: 2AM

On Leai: 2AM

On Skywalker: 2AM

On Coruscant: 11PM

5.3.4.2 Overview of MS SQL Backup and Recovery (Octane)

The backup process for the MS SQL Server databases is automated from the database perspective.

On both ots0 and ots1 we have established "Maintenance Plans" within SQL Server. The Maintenance Plans automate three functions, as follows: 1) integrity checking, 2) database compression, and 3) backup to disk. These are timed daily at 12:01 AM, 12:06 AM and 12:11 AM, respectively. The third step should always be complete by 12:30 AM.

We have created "at jobs" on both boxes to fire at 2 AM daily. These jobs execute the script named "backup_mssql_ots0.bat" and "backup_mssql_ots1.bat", respectively. Two additional batch files have been written to re-create the "at jobs" should they accidentially get deleted. These scripts are named "at_backup_ots0.bat" and "at_backup_ots1.bat". These scripts should not be re-run if the "at jobs" are present. All four files have been tested extensively and stored in VSS.

The compressed files, octane-yyyymmdd.zip, are left in e:\mssql7\backup on each server. They are transferred to the ftp server on tucson under "octane\ots0" and "octane\ots1", respectively. One additional file is transferred with each ZIP file named "noerrors". If this file is not present there was a problem with the compression -- typically it means the backup files were not present to compress. On the server-side, if there were errors there will be a file named "errors". This is the inverse of "noerrors" on the ftp server side, and usually means the same thing. Other temporary files used are automatically cleaned up with a normal exit.

The scripts may be viewed in VSS or on the server in e:\mssql7\backup.

The automation of sending a copy of the octane database (only) to Service uses the same technique as described above but the target ftp server is camserver. Service retrieves their copy every Monday morning. An FTP account id of: service, has been set up for their use.

There is an "at command" on my box, Tucson, which can be recreated with the following batch file:

at_tucson.bat

The "at command" executes the following script on Monday mornings at 7 AM:

i:\ftproot\service\tucson_to_service.bat

This batch file takes the Monday .zip file, which was placed on Tucson at 2 AM, and extracts the "b_octane_db_2000xxxxxxxx.BAK" file (where "x" is some variable). After this file is extracted, it creates a new .zip file that contains only this database backup file. This smaller .zip file is then ftp'ed to the public site, mentioned below, and all temporary files, and the local .zip file, are deleted. The file named "noerrors" is left to indicate the time of completion, should there be a question as to whether the process worked.

We are currently putting these files (octane-2000xxxx.zip, and "noerrors") in the "incoming" directory. I can not view the files; but after testing the second time I see that I get the message "permission denied on server (overwrite)", so I assume I have made the connection properly.

When the new directory, with permissions for Service, is created we will change the script. The "at command" is currently set and ready to go. Files are stored in VSS for your review.

The compressed files should still be backed up to tape and maintained per the O&M procedures. The database backups have been tested on my machine; but it should be noted that "full-text search" capabilities couldn’t be implemented on an NT Workstation, so we still don't have a 100% test of these files.

You really can't back up a database while its' operational. To back up the files "cold" the database "service" must be stopped; but to really be sure you're backed up, you must export, backup, dump, unload, etc. the files... depending on the vendor. With MS it's "backup". We do not backup the "system" database, as they would be recovered with a rebuild from CDROM. And the "automation" features of MS SQL Server do not function as advertised.

5.3.5 Database Handling

5.3.5.1 Monitoring

There is a crontab entry on Skywalker, Leia, Coruscant, and Tatooine that runs six times a day at the following times: 3:45, 7:45, 11:45 AM and PM, seven days a week. It executes a Unix shell script on each box that creates a number of HTML files that are then downloaded to the PC at David Russell’s desk. There is an FTP server on this PC to receive the files, as well as a web server to publish them.

Access it at the following URL http://tucson/oralogs/.

You can review Oracle related information about disks, processes, logs, etc. Later, it will also report on backup completion status. (Sri, I’m waiting for information on this. John, this will change when we implement Oracle Recovery Manager (RMAN)).

The Oracle Financial instances are not totally supported by this tool. There are a number of issues with the “listeners” on the Oracle applications.

As the Oracle DBA, it's my default page. It is monitored several times a day, and when I’m called in during the night, it’s the first thing I go for to see what’s happening with a troubled machine.

Note: I hope that the FTP server and access to these files can be accomplished on my home machine, too. Total configuration of that environment needs to be done, time permitting.

5.3.5.2 Maintenance

TBD, at a minimum, init<sid>.ora files need to be hard-copies here…

Plus UNIX (/ext/system) semaphores settings…

(Or, we could reference a copy in the Technical Reference Manuals.)

5.3.5.3 Tuning

TBD

5.3.5.4 Support

<snip>

5.3.5.5 Database Configuration (Moai Instances)

The following Oracle parameters are identical on each of our Moai Oracle instances. The ones that are unique, per instance, follow in a separate section. This list does not necessarily represent non-default values. There are additional Oracle parameters that default to known values and are occasionally changed.

The best place to view these parameters, per instance, is within the Oracle directory structure at $ORACLE_BASE/admin/<SID>/pfile/init<SID>.ora If an instances is running, the best way to get the values is to query the database (svrmgrl: show parameters).

Oracle Financial settings will appear separately... (TDB). They can be viewed in $ORACLE_HOME/dbs/init<SID>.ora (note the different location).

db_domain = <defunct>.com

db_block_buffers = 8192

shared_pool_size = 52428800

java_pool_size = 20971520

log_checkpoint_interval = 10000

log_checkpoint_timeout = 1800

processes = 200

log_buffer = 163840

log_archive_start = true

log_archive_format = %t_%s.dbf

rollback_segments = (r01, r02, r03, r04)

global_names = true

db_block_size = 8192

remote_login_passwordfile = exclusive

os_authent_prefix = ""

job_queue_processes = 0

job_queue_interval = 60

distributed_transactions = 10

open_links = 4

mts_dispatchers = "(PROTOCOL=TCP)(PRE=oracle.aurora.server.SGiopServer)"

mts_servers = 1

compatible = "8.1.0"

nls_date_format = DD-MON-RRRR

nls_numeric_characters = ".,"

nls_sort = binary

nls_language = AMERICAN

nls_territory = AMERICA

initMOAIDEV.ora settings unique to MOAIDEV (Skywalker)

db_name = MOAIDEV

instance_name = MOAIDEV

service_names = MOAIDEV.<defunct>.com

control_files = ("/u02/oradata/MOAIDEV/control01.ctl", "/u02/oradata/MOAIDEV/control02.ctl")

log_archive_dest_1 = "location=/u03/oradata/MOAIDEV/arch"

background_dump_dest = /u01/app/oracle/admin/MOAIDEV/bdump

core_dump_dest = /u01/app/oracle/admin/MOAIDEV/cdump

user_dump_dest = /u01/app/oracle/admin/MOAIDEV/udump

initMOAITST.ora settings unique to MOAITST (Leia)

db_name = MOAITST

instance_name = MOAITST

service_names = MOAITST.<defunct>.com

control_files = ("/u04/oradata/MOAITST/control01.ctl", "/u04/oradata/MOAITST/control02.ctl")

log_archive_dest_1 = "location=/u05/oradata/MOAITST/arch"

background_dump_dest = /u01/app/oracle/admin/MOAITST/bdump

core_dump_dest = /u01/app/oracle/admin/MOAITST/cdump

user_dump_dest = /u01/app/oracle/admin/MOAITST/udump

initMOAIPROD.ora settings unique to MOAIPROD (Tatooine)

db_name = MOAIPROD

instance_name = MOAIPROD

service_names = MOAIPROD.<defunct>.com

control_files = ("/u06/oradata/MOAIPROD/control01.ctl", "/u06/oradata/MOAIPROD/control02.ctl")

log_archive_dest_1 = "location=/u07/oradata/MOAIPROD/arch"

background_dump_dest = /u01/app/oracle/admin/MOAIPROD/bdump

core_dump_dest = /u01/app/oracle/admin/MOAIPROD/cdump

user_dump_dest = /u01/app/oracle/admin/MOAIPROD/udump

5.3.5.6 Oracle Net8 Configuration

The Oracle Net8 configuration requires three files to be located at /var/opt/oracle: listener.ora, sqlnet.ora, and tnsnames.ora. They are slightly different on each platform. They are all included here in case something happens to the disk copies.

<one for each host – duplicated omitted here>

Listener.ora

LISTENER =

(DESCRIPTION_LIST =

(DESCRIPTION =

(ADDRESS_LIST =

(ADDRESS = (PROTOCOL = IPC)(KEY = EXTPROC0))

)

(ADDRESS_LIST =

(ADDRESS = (PROTOCOL = TCP)(HOST = skywalker)(PORT = 1521))

)

(DESCRIPTION =

(PROTOCOL_STACK =

(PRESENTATION = GIOP)

(SESSION = RAW)

)

(ADDRESS = (PROTOCOL = TCP)(HOST = skywalker)(PORT = 2481))

)

SID_LIST_LISTENER =

(SID_LIST =

(SID_DESC =

(SID_NAME = PLSExtProc)

(ORACLE_HOME = /u01/app/oracle/product/8.1.5)

(PROGRAM = extproc)

)

(SID_DESC =

(GLOBAL_DBNAME = moaidev.<defunct>.com)

(ORACLE_HOME = /u01/app/oracle/product/8.1.5)

(SID_NAME = MOAIDEV)

)

(SID_DESC =

(GLOBAL_DBNAME = moaiclon.<defunct>.com)

(ORACLE_HOME = /u01/app/oracle/product/8.1.5)

(SID_NAME = MOAICLON)

)

Sqlnet.ora

SQLNET.AUTHENTICATION_SERVICES = (NONE)

AUTOMATIC_IPC = OFF

USE_DEDICATED_SERVER = OFF

NAMES.DEFAULT_DOMAIN = <DEFUNCT>.COM

NAMES.DIRECTORY_PATH = (TNSNAMES)

SQLNET.EXPIRE_TIME = 0

Tnsnames.ora

EXTPROC_CONNECTION_DATA =

(DESCRIPTION =

(ADDRESS_LIST =

(ADDRESS = (PROTOCOL = IPC)(KEY = EXTPROC0))

)

(CONNECT_DATA =

(SID = PLSExtProc)

(PRESENTATION = RO)

)

BEQ-LOCAL.<DEFUNCT>.COM

(DESCRIPTION =

(ADDRESS_LIST =

(ADDRESS = (PROTOCOL = BEQ) (PROGRAM = oracle)

(ARGV0 = MOAIDEV)

(ARGS = '(DESCRIPTION=(LOCAL=YES)(ADDRESS=(PROTOCOL=beq)))')

)

(CONNECT_DATA = (SID = MOAIDEV)

)

BEQ-LOCAL.<DEFUNCT>.COM

(DESCRIPTION =

(ADDRESS_LIST =

(ADDRESS = (PROTOCOL = BEQ) (PROGRAM = oracle)

(ARGV0 = MOAICLON)

(ARGS = '(DESCRIPTION=(LOCAL=YES)(ADDRESS=(PROTOCOL=beq)))')

)

(CONNECT_DATA = (SID = MOAICLON)

)

MOAICLON =

(DESCRIPTION =

(ADDRESS_LIST =

(ADDRESS = (PROTOCOL = TCP)(HOST = skywalker)(PORT = 1521))

)

(CONNECT_DATA =

(SERVICE_NAME = moaiclon.<defunct>.com)

)

MOAITST =

(DESCRIPTION =

(ADDRESS_LIST =

(ADDRESS = (PROTOCOL = TCP)(HOST = leia)(PORT = 1521))

)

(CONNECT_DATA =

(SERVICE_NAME = moaitst.<defunct>.com)

)

MOAIDEV =

(DESCRIPTION =

(ADDRESS_LIST =

(ADDRESS = (PROTOCOL = TCP)(HOST = skywalker)(PORT = 1521))

)

(CONNECT_DATA =

(SERVICE_NAME = moaidev.<defunct>.com)

)

<snip>

5.3.5.7 Other Issues

TBD

5.3.6 Availability Of Spare Parts

Availability Of Spare Parts maintains hardware as part of the contingency plan. A router specified for connection to AboveNet is unused and can serve as a spare router. Two spare NIC cards are maintained. Spare cables are available from SimpleNet. Each A1000 unit has a hot spare disk. Sun Monitor and keyboard and a NT monitor and keyboard are available from SimpleNet.

5.3.7 Corrective Maintenance

SimpleNet provides a service – to ping the website address of www.<defunct>.com. A failure of a successful ping shall trigger a page to the pager carried by <snip> in that order. The engineer who receives the page shall remote access the business site VPN and then access the network management application to perform fact finding. The remote access equipment shall consist of a laptop with regular and cell modem capabilities. Once the fact finding process has been completed, the engineer shall make a determination as to the possible cause of the problem. The appropriate vendor shall be contacted using the Support Contract number for <defunct>.com. The vendor contact numbers and our support contract or reference numbers shall be obtained from the Vendor Contacts Section.

5.3.8 Preventative Maintenance

cronjobs monitor disk usage and file system space. Oracle log and temporary files deleted weekly. SNMP agents are enabled in the A1000, E250, E450, the Ultra-10 running the FW and the Ultra-10 running the Accrue Analyzer. All the data shall be captured by Network Management Software, HP Open View.

5.3.9 Change Requests

All change requests, maintenance and upgrades shall be documented by a rfc.

5.3.10 Change Control

5.4 Accounting Management

5.4.1 Track Service Usage

5.4.2 Monitor Service Quality Trends

5.4.3 Supply of Statistical Information as a Basis for Expansion

SAS

5.5 Performance Management

5.5.1 Data Collection

top, sar reports, cron jobs

Performance Measurement

Monitor Service Quality Trends

5.5.2 Report Generation

5.5.3 Data Analysis

5.6 Security Management

Oracle here

Octane here, too

TBD

Absolutely will want to cover many issues… all those accounts with default passwords, and other holes.

No account can have default passwords.

SQL*Server default “sa” password

5.6.1 Control Network Element Access

5.6.2 Enable Network Element Functions

5.6.3 Access Logs

6. References

[1] <defunct>.com Web Design And Layout, <defunct>\Mock.Html, Version 4.0, 9/8/99. (Jeremy) Error! Bookmark not defined.

[2] Use Case Diagrams, Uc-1-N.Vsd, 9/9/99. (Scott) Error! Bookmark not defined.

[3] White Paper, Technology Analysis and Recommendations, White Paper.doc, 9/30/99. (Terry) Error! Bookmark not defined.

[4] <defunct>.com Website Functional Specifications, Functional Specifications.doc, Rev 1.7 10/13/99. (Terry) Error! Bookmark not defined.

[5] Engineering Schedule, <defunct> Engineering Revised Schedule2.mpp, 11/20/99. (Renee) Error! Bookmark not defined.

[6] Network Management, Network Management.doc, 5/95. (Douglas Stevenson) Error! Bookmark not defined.

Network Entities	Description
ISP	Simplnet located at 225 Broadway, 13^th Floor, San Diego, CA 92101
T1	1 point to point connection to the business site provide by ICG Telecom Group, Inc., 5 Park Plaza, Ste. 1600, Irvine, CA 92614
VPN	CheckPoint Firewall-1 VPN-1 version 4.0 25 user
Ethernet	Cat 5 Cables, Cross-over cables
Hub	Cisco FastHub 400
Router	Cisco 2610 with 2 Ethernet ports and 1 T1 module
Switch	Cisco 2912-XL/A Ethernet Switch
Battery Backup	APC
NT Agents	Netback client
NT Email Server	NT 4.0 SP5
Sun Print Server	E-250, Solaris 2.6
Sun Application Server	E-450, Solaris 2.6
Sun Backup Server	Netra t1, Solaris 2.7
Sun Firewall Server	U-10, Solaris 2.6
Sun Network Monitor	U-10, Solaris 2.6
Sun Raid	A1000
Sun Web Monitor	U-10, Solaris 2.6
Sun Financials Server	E-250, Solaris 2.6

Part #	Model #	Vendor	Purpose	Severity	Replacement	Support Contact
1.	E450	Sun	Application Server	Mission Critical (MC)	New purchase	(800) 872-4786
2.	E250	Sun	Financials Server	MC	New purchase	(800) 872-4786
3.	A1000	Sun	Storage	MC	New purchase	(800) 872-4786
4.	A1000	Sun	Storage	MC	New purchase	(800) 872-4786
5.	A1000	Sun	Storage	MC	New purchase	(800) 872-4786
6.	U10	Sun	Firewall	MC	New purchase	(800) 872-4786
7.	U10	Sun	Traffic Analyzer	MC	New purchase	(800) 872-4786
8.	2610	Cisco	Router	MC	New purchase	(800) 553-2447
9.	2610	Cisco	Router	MC	New purchase	(800) 553-2447
10.	2610	Cisco	Router	MC	New purchase	(800) 553-2447
11.	2912	Cisco	Router	MC	New purchase	(800) 553-2447
12.	L200	ATL	Tape Library	MC	New purchase	(800) 284-5101
13.	P2300	DELL	Application Server	MC	New purchase
14.	P6300	DELL	Application Server	MC	New purchase
15.		Check-Point	Firewall Application	MC	Upgrade from vendor	(650) 628-2000
16.		Veritas	Applications	MC	Upgrade from vendor	(800) 258-8649

Item Name	Description
PBX	Lucent Definity G2
Phone Deskset	Lucent 6408D+
Phone Dispatch	Lucent 6424D+, XM24
POTS	18 analog lines.
Voice Mail System	Octel VMS
Business Site Network Entities	Description
ISP	Simplnet located at 225 Broadway, 13^th Floor, San Diego, CA 92101
T1	1 point to point connection to the business site provide by ICG Telecom Group, Inc., 5 Park Plaza, Ste. 1600, Irvine, CA 92614
VPN	CheckPoint Firewall-1 VPN-1 version 4.0 50 user
Ethernet	Cat 5 Cables, Cross-over cables
Hub	Cisco FastHub 400
Router	Cisco 2610 with 2 Ethernet ports and 1 T1 module
Switch	Cisco 2912-XL/A Ethernet Switch
Battery Backup	APC
NT Agents	Netback client, Arcserver client
NT Backup Server	NT 4.0 SP5, arcserver
NT DHCP Server	NT 4.0 SP5
NT Email Server	NT 4.0 SP5
NT Firewall Server	NT 4.0 SP5, CheckPoint Firewall-1 version 4.0 100 user.
NT Print Server	NT 4.0 SP5
NT Utilities	DHCP Manager, WINS Server
Linux ftp server	Pentium, Linux

Part #	Model #	Vendor	Purpose	Severity	Replacement	Support Contact
1.	Pentium	Micropage	File Server	Mission Critical	New purchase
2.	Pentium	Octel	Voice Mail	Mission Critical	New purchase
3.	2500	Compaq	Mail Server	Mission Critical	New purchase
4.	800	Compaq	Firewall Server	Mission Critical	New purchase	(650) 628-2000
5.	2600	Cisco	Router	Mission Critical	New purchase	(800) 553-2447
6.	2600	Cisco	Router	Mission Critical	New purchase	(800) 553-2447
7.	2912	Cisco	Switch	Mission Critical	New purchase	(800) 553-2447
8.	400	Cisco	Hub	Mission Critical	New purchase	(800) 553-2447
9.	400	Cisco	Hub	Mission Critical	New purchase	(800) 553-2447
10.	400	Cisco	Hub	Mission Critical	New purchase	(800) 553-2447
11.	400	Cisco	Hub	Mission Critical	New purchase	(800) 553-2447

Network Entity	Description
ISP	Simplenet located at 225 Broadway, 13^th Floor, San Diego, CA 92101 619-881-3090
T1	1 point to point connection to the business site provide by ICG Telecom Group, Inc., 5 Park Plaza, Ste. 1600, Irvine, CA 92614
Ethernet	Cat 5 Cables, Cross-over cables
Hub	Intel Fast hub
Switch	Cisco 2912-XL/A Ethernet Switch
Battery Backup	APC
NT Agents	Netback client
NT Email Server	NT 4.0 SP5
Sun Print Server	E-250, Solaris 2.6
Sun Application Test Server	E-450, Solaris 2.6
Sun Backup Test Server	Netra t1, Solaris 2.7
Sun Raid	A1000
Sun Development Server	E-250, Solaris 2.6

Disk	Contents
1	Oracle database software
2	System, Tools, and Indexes_2 tablespaces, Control file 1
3	RBS, and RBS_2 tablespace, Control file 2
4	Data tablespace, Control file 3
5	Indexes, Temp, Temp_user, and Data_2 tablespaces
6	Online Redo logs 1, 2, and 3, Export dump file destination disk
7	Application software, archived redo log destination disk

Logical Drive	Contents
1 (mirrored)	Oracle database software is located on a disk on the server, not the RAID box
2 (consists of 4 striped and mirrored drives)	System, Tools, and Indexes_2 tablespaces, Control file 1, RBS, and RBS_2 tablespace, Control file 2, Data tablespace, Control file 3, Indexes, Temp, Temp_user, and Data_2 tablespaces, Online Redo logs 1, 2, and 3
3 (consists of 2 unstriped drives)	Export dump file destination disk
4 (1 or 2 mirrored drives)	Application software, archived redo log destination disk
